ACS355 Minimum required parameter settings for PROFINET
The minimum required parameter settings are based on factory default settings.
Parameter
Description
Setting
Comment
98.02
COMM PROT
SEL
EXT FBA
Activates fieldbus module
51.01
FBA A type
Ethernet
Fieldbus type
51.02
Protocol/Profile
PNIO ABB Pro (11)
Communication profile ABB drives
51.04
IP Configuration
Static (0)
-
51.05 ...
51.08
IP address
192.xxx.xx.xx or any other
required IP address.
-
51.09
Subnet CDR
24
24 For subnet mask 255.255.255.0
51.27
FBA PAR
REFRESH
REFRESH
Updates fieldbus settings (groups 51 to 55)
10.01
EXT1
COMMANDS
COMM
Fieldbus interface as a source for start and
stop.
11.03
REF1 SELECT
COMM
Fieldbus interface as a source for speed
reference
16.04
FAULT RESET
SEL
COMM
Fieldbus interface as a source for fault
reset
(11.05)
REF1 MAX
[Scale max]
Max speed/frequency scaling value (used
in function block/visualization input
SPEED_REF_MAX). Must be less or equal
to drive parameter max speed/frequency.
ACS355 More parameters read from drive to PLC (optional)
Parameter
Description
Setting
Comment
54.03 …
54.10
Actual value or
parameter of drive
GGii
GG = parameter group, ii = parameter index
Example, 0104 = actual current; 0145 = motor temp
51.27
FBA PAR
REFRESH
REFRESH
Updates fieldbus settings (groups 51 to 55)
