ABB ACSM1 Series User Manual

19
20.01
Ext 1 commands
Fieldbus A
Fieldbus interface as source for start and stop
22.11
Ext1 speed ref1
FB A ref1
Fieldbus interface as source for speed
reference
31.11
Fault reset selection
P.06.01 bit 7
Fieldbus interface as source for fault reset
(46.01)
Speed scaling
[Scale max]
Max speed/frequency scaling value (used in
function block/visualization input
SPEED_REF_MAX). Must be less or equal to
drive parameter max speed/frequency.
ACS380 More parameters read from drive to PLC (optional)
Parameter
Description
Setting
Comment
52.03 …
52.12
Actual value or
parameter of drive
GGii
GG = parameter group, ii = parameter index
Example, 0107 = actual current; 3501 = motor est.
temp
51.27
FBA PAR
REFRESH
REFRESH
Updates fieldbus settings (groups 50 to 57)
ACS380 More parameters written from PLC to drive (optional)
Parameter
Description
Setting
Comment
53.03 …
53.12
Parameter of
drive
GGii
GG = parameter group, ii = parameter index
Example, 2312 = acceleration time 1
51.27
FBA PAR
REFRESH
REFRESH
Updates fieldbus settings (groups 50 to 57)
