ABB ACSM1 Series User Manual

41
ACSM1 Minimum required parameter settings for PROFINET
The minimum required parameter settings based on factory default settings.
Parameter
Description
Setting
Comment
50.01
FBA ENABLE
Enable
Activates fieldbus module.
51.01
FBA A ype
Ethernet
Filedbus type.
51.02
Protocol/Profile
PNIO ABB Pro (11)
Communication profile ABB drives.
51.04
IP Configuration
Static (0)
-
51.05 ...
51.08
IP address
192.xxx.xx.xx or any other
required IP address.
-
51.09
Subnet CDR
24
24 For subnet mask 255.255.255.0.
51.27
FBA PAR
REFRESH
REFRESH
Updates fieldbus settings (groups 51
to 55).
52.01
FBA DATA IN1
4
Status word as Data Word 1 from the
drive.
52.02
FBA DATA IN2
5
Actual speed as Data Word 2 from
the drive.
53.01
FBA DATA OUT1
1
Control word as Data Word 1 to the
drive.
53.02
FBA DATA OUT2
2
Speed reference as Data Word 2 to
the drive.
10.01
EXT1 START
FUNC
FBA
Fieldbus interface as source for start
and stop.
24.01
SPEED REF1
SEL
FBA REF1
Fieldbus interface as source for
speed reference.
10.08
FAULT RESET
SEL
P.02.12 bit 8
Fieldbus interface as source for fault
reset.
(25.02)
SPEED SCALING
[Scale max]
Max speed/frequency scaling value
(used in function block/visualization
input SPEED_REF_MAX). Must be
less or equal to drive parameter max
speed/frequency.
