ACS850 Minimum required parameter settings for PROFINET
The minimum required parameter settings based on factory default settings.
Parameter
Description
Setting
Comment
50.01
Fba enable
Enable
Activates fieldbus module
51.01
FBA A type
Ethernet
Fieldbus type
51.02
Protocol/Profile
PNIO ABB Pro (11)
Communication profile ABB drives
51.04
IP Configuration
Static (0)
-
51.05 ...
51.08
IP address
192.xxx.xx.xx or any other
required IP address.
-
51.09
Subnet CDR
24
24 For subnet mask 255.255.255.0
51.27
FBA PAR
REFRESH
REFRESH
Updates fieldbus settings (groups 51
to 55)
10.01
Ext1 start func
FB
Fieldbus interface as source for start
and stop
10.10
Fault reset sel
P.02.22 bit 8
Fieldbus interface as source for fault
reset
(19.01)
Speed scaling
[Scale max]
Max speed/frequency scaling value
(used in function block/visualization
input SPEED_REF_MAX). Must be
less or equal to drive parameter max
speed/frequency.
21.01
Speed ref1 sel
FBA ref1
Fieldbus interface as source for
speed reference
