Canon imagePROGRAF iPF770 User Manual

• The Power Lamp and Message Lamp are not lit (even once), and nothing appears on the
Display Screen
Make sure the printer is plugged in correctly. Check the connection at the plug and electrical outlet.
• No paper is loaded
Load paper. (See "Loading and Printing on Rolls.") ➔P.16 (See "Loading and Printing on
Sheets.") ➔P.18
Turning the printer off
Important
• Never disconnect the printer's power supply or unplug it during a print job. This may damage the printer.
1
Make sure no print jobs are in progress.
If the Message Lamp is flashing, check the message on the Dis-
play Screen and take action as necessary. (See "Error Messag-
es.") ➔P.554
If the Data Lamp is flashing, the printer is receiving a print job.
Turn off the printer only after printing is finished.
2
Hold down the Power button for more than a second.
After "Shut Down.. Please Wait.." is shown on the Display
Screen, the printer shuts off.
Loading and Printing on Rolls
Loading and Printing on Rolls
These are the basic steps for loading and printing on rolls.
Follow these steps to load and print on rolls.
Note
•
For details on supported sizes and types of rolls, see Paper Sizes or the Paper Reference Guide. (See "Paper
Sizes.") ➔P.310 (See "Types of Paper.") ➔P.310
• If you prefer to wait for the ink to dry after printing and simply eject the document, you can deactivate automatic
cutting and cut the paper manually. (See "Specifying the Cutting Method for Rolls.") ➔ P.333
Loading and Printing on Rolls iPF770
User's Guide
Basic Printing Workflow Printing procedure
16

Canon imagePROGRAF iPF770 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Certification	CE, TUV, Gost-R, WEEE, ErP, EAC, RoHS, WEEE
Product color	Black, Grey
Sound pressure level (printing)	46 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet interface type	Gigabit Ethernet
Media thickness	0.07 - 1.5 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll length	18 m
Media width (sheets)	914.4 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
Borderless printing media sizes	A0, A1, A2, A3, B4
Minimum system requirements	Windows XP, Vista, 7, 8, 8.1, Server 2003/2003R2, Server 2008/2008R2, Server 2012/2012R2 Mac X 10.6.8 - 10.10+
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR
Accuracy	0.2 %
Scan speed (black)	3 ips
Scan speed (color)	1 ips

Weight and Dimensions

Depth	1100 mm
Width	1304 mm
Height	1062 mm
