9
The Confirm Update dialog box is displayed.
Configure Update Target and click the Execute but-
ton.
The printer control panel and printer driver media in-
formation is updated.
Note
• You should normally select Update the printer control panel and printer driver.
10
The message on the right is displayed.
If you want to save the current media information in a file,
click the Yes button. If you do not want to save it, click the
No button.
Note
•
The media information is saved as a media information file (.amx file).
• For the method for loading a saved media information file in another computer, see "Applying a Saved
Media Information File on Another Computer." ➔ P.371
Media Configuration Tool Main Window
Media Configuration Tool Main Window
The explanation below is on the Media Configuration Tool main window.
Use the following procedure to open Media Configuration Tool main window.
Important
•
Do not attempt to print or turn the printer off while the program is communicating with the printer.
1 From the start menu, select All Programs > imagePROGRAF Media Configuration Tool > imagePROG-
RAF Media Configuration Tool.
2
The Select Printer dialog box is displayed. Select
the printer for which to configure the media informa-
tion, and then click the Next button.
Note
•
If you are using the printer without installing the printer driver, click the Specify a printer that is not in-
stalled button and specify the printer by following the on-screen instructions.
• In the following screens, you cannot change the printer where media type information is to be updated.
iPF770 Media Configuration Tool Main Window
User's Guide
Handling and Use of Paper Media Configuration Tool (Windows)
357

Canon imagePROGRAF iPF770 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Certification	CE, TUV, Gost-R, WEEE, ErP, EAC, RoHS, WEEE
Product color	Black, Grey
Sound pressure level (printing)	46 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet interface type	Gigabit Ethernet
Media thickness	0.07 - 1.5 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll length	18 m
Media width (sheets)	914.4 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
Borderless printing media sizes	A0, A1, A2, A3, B4
Minimum system requirements	Windows XP, Vista, 7, 8, 8.1, Server 2003/2003R2, Server 2008/2008R2, Server 2012/2012R2 Mac X 10.6.8 - 10.10+
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR
Accuracy	0.2 %
Scan speed (black)	3 ips
Scan speed (color)	1 ips

Weight and Dimensions

Depth	1100 mm
Width	1304 mm
Height	1062 mm
