Canon imagePROGRAF iPF770 User Manual

• G No Spaces at Top or Bottom (Conserve Paper)
Activate this setting to print the next image skipping blank areas above and below printable data in documents,
which enables you to conserve the paper.
• Conserving Roll Paper by Printing Originals Without Top and Bottom Margins ➔ P.124
•
H Copies
Enter the number of copies to print, in a range of 1–999.
• Reverse Order
Activate this option to print pages in reverse order.
• Collate
Activate this option to print complete sets in the specified quantity.
• I Page Options
Click to display the Page Options dialog box, which enables you to complete settings for printing the user
name, date, or page number in the header or footer.
• Page Options Dialog Box ➔P.163
• J Special Settings
If the printing results are not as you expected, click this option to display the Special Settings dialog box and
change how printing is processed.
• Special Settings Dialog Box ➔P.164
• S Defaults
Click to restore all settings on the sheet to the default values.
Page Options Dialog Box
Page Options Dialog Box
The Page Options dialog box offers the following settings.
Note
•
To display the Page Options dialog box, on the Layout sheet, click Page Options. (See "Layout Sheet .") ➔ P.162
•
A
Print Date
Select where the date is printed, as desired. To print the time as well, select B Print Time Also.
• C
Print User Name
Select where the user name is printed, as desired.
• D
Print Page Number
Select where the page number is printed, as desired.
iPF770
Page Options Dialog Box
User's Guide
Windows Software Printer Driver
163

Canon imagePROGRAF iPF770 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Certification	CE, TUV, Gost-R, WEEE, ErP, EAC, RoHS, WEEE
Product color	Black, Grey
Sound pressure level (printing)	46 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet interface type	Gigabit Ethernet
Media thickness	0.07 - 1.5 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll length	18 m
Media width (sheets)	914.4 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
Borderless printing media sizes	A0, A1, A2, A3, B4
Minimum system requirements	Windows XP, Vista, 7, 8, 8.1, Server 2003/2003R2, Server 2008/2008R2, Server 2012/2012R2 Mac X 10.6.8 - 10.10+
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR
Accuracy	0.2 %
Scan speed (black)	3 ips
Scan speed (color)	1 ips

Weight and Dimensions

Depth	1100 mm
Width	1304 mm
Height	1062 mm
