Canon imagePROGRAF iPF770 User Manual

6
As necessary, set the print conditions in the hot fold-
er. (See "Setting the Print Parameters.") ➔P.208
Click the OK button to close the Add/Edit Hot Fold-
er dialog box.
The hot folder you have created appears in the Hot
Folder list in the Color imageRUNNER Enlarge-
ment Copy dialog box.
Setting the Print Parameters
Setting the Print Parameters
The printer driver opens when you click the Properties button in the Add/Edit Hot Folder dialog box. The printer
driver is used to configure basic settings to match the type of media loaded in the printer.
Refer to "Printer Driver" ➔P.140 for details on the printer driver.
Setting the Print Parameters iPF770
User's Guide
Windows Software Color imageRUNNER Enlargement Copy
208

Canon imagePROGRAF iPF770 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Certification	CE, TUV, Gost-R, WEEE, ErP, EAC, RoHS, WEEE
Product color	Black, Grey
Sound pressure level (printing)	46 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet interface type	Gigabit Ethernet
Media thickness	0.07 - 1.5 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll length	18 m
Media width (sheets)	914.4 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
Borderless printing media sizes	A0, A1, A2, A3, B4
Minimum system requirements	Windows XP, Vista, 7, 8, 8.1, Server 2003/2003R2, Server 2008/2008R2, Server 2012/2012R2 Mac X 10.6.8 - 10.10+
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR
Accuracy	0.2 %
Scan speed (black)	3 ips
Scan speed (color)	1 ips

Weight and Dimensions

Depth	1100 mm
Width	1304 mm
Height	1062 mm
