Canon imagePROGRAF iPF770 User Manual

Menu Structure
Menu Structure
The menu structure is shown categorized by tab. The * on the right side of an item indicates the default value.
The printer menu is classified into regular menu items available when no print job is in progress and menu during
printing items only available while printing is in progress. see "Printer Menu Operations." ➔P.406
Regular menu Menu during printing
Paper Menu
Not displayed
Ink Menu The same Ink Menu as normal is displayed.
Job Menu The same Job Menu as normal is displayed.
Set./Adj. Menu A limited Set./Adj. Menu containing the following items is displayed.
• Adj. Fine Feed(*1)
• Printer Info
*1: Only displayed in the menu during printing. Not displayed in the regular menu.
For instructions on menu operations, see "Menu Operations." ➔P.407
For details on menu items, see "Menu Settings." ➔P.416
Paper Menu
The Paper Menu is not displayed during printing.
First Level Second Level Third Level Fourth Level Fifth Level
Load Paper Roll Paper | Cut Sheet
Eject Paper
Chg. Paper Type(*1) Roll Paper (The paper type is displayed here.) (*1)
Cut Sheet (The paper type is displayed here.) (*1)
Chg. Paper Size Sheet Size (The size of paper is displayed here.) (*2)
CustomPaperSize (Set the length and width)
Roll Length(*3) (Set the length)
Roll Width(*4) (Set the width)
ManageRemainRoll Off* | On
Paper Details (The paper type is dis-
played here.) (*1)
Head Height Automatic* | Highest | High | Standard | Low |
Lowest | Super Low
Skew Check Lv. High Accuracy | Standard* | Loose | Off
Cutting Mode(*6) Automatic | Eject | Manual
Cut Speed Fast | Standard | Slow
Trim Edge First Automatic | Off | On (Preset Len) | On(Input
Length) | Manual
CutDustReduct. Off | On
VacuumStrngth Automatic* | Strongest | Strong | Standard | Weak
| Weakest
Scan Wait Time Dry time Off* | 1 sec. | 3 sec. |
5 sec. | 7 sec. | 9 sec.
Area(*5) Entire area* | Leading
edge
Roll DryingTime Off | 30 sec. | 1 min. | 3 min. | 5 min. | 10 min. | 30
min. | 60 min.
NearEnd RollMrgn 3mm | 20mm
NearEnd Sht Mrgn 3mm | 20mm
BordlessOversize Standard* | Little
Width Detection Off | On*
Return Defaults
Paper Details
Keep Paper Type Off* | On
Menu Structure iPF770
User's Guide
Control Panel Printer Menu
410

Canon imagePROGRAF iPF770 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Certification	CE, TUV, Gost-R, WEEE, ErP, EAC, RoHS, WEEE
Product color	Black, Grey
Sound pressure level (printing)	46 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet interface type	Gigabit Ethernet
Media thickness	0.07 - 1.5 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll length	18 m
Media width (sheets)	914.4 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
Borderless printing media sizes	A0, A1, A2, A3, B4
Minimum system requirements	Windows XP, Vista, 7, 8, 8.1, Server 2003/2003R2, Server 2008/2008R2, Server 2012/2012R2 Mac X 10.6.8 - 10.10+
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR
Accuracy	0.2 %
Scan speed (black)	3 ips
Scan speed (color)	1 ips

Weight and Dimensions

Depth	1100 mm
Width	1304 mm
Height	1062 mm
