Canon imagePROGRAF iPF770 User Manual

Set./Adj. Menu
Limited items are displayed during printing. The displayed items are indicated by annotations.
Setting Item Description, Instructions
Test
Print
Nozzle Check Print a test pattern to check the nozzles.
Status Print Print information about the setting values and condition of
the printer.
Interface Print Print interface settings information.
GL2 Set Print Print the settings as specified in GL2 Settings.
Paper Details Print the paper settings as specified in Paper Details.
Print Job Log Print Job Log information.
The maximum number of history records in models fitted
with a hard disk is 32.
The maximum number of history records in models not fit-
ted with a hard disk is 10.
Menu Map Print the menu structure.
Color Palette Print the GL2 color palette.
Adjust
Printer
Head
Posi.
Adj.
Auto(Standard) The printer prints and reads a test pattern for automatic
adjustment of Printhead alignment relative to the printing
direction. (See "Automatic Adjustment to Straighten Lines
and Colors.") ➔P.480
Auto(Advanced) The printer prints and reads a test pattern for automatic
adjustment of Printhead alignment relative to the printing
direction and spacing between nozzles and colors. (See
"Automatic Adjustment to Straighten Lines and Col-
ors.") ➔P.480
Manual Print a test pattern for adjustment of Printhead alignment
relative to the printing direction. Enter the adjustment val-
ue manually based on the resulting pattern. (See "Manual
Adjustment to Straighten Lines and Colors.") ➔ P.481
Head Inc. Adj. Print a test pattern for adjustment of the Printhead orienta-
tion. (See "Adjusting Line Misalignment.") ➔ P.483
Feed
Priority
Adj. Pri-
ority
Automatic Specify exact paper feeding, if desired. Normally, select
Automatic. Choose Print Quality for attractive printing.
Choosing Print Quality also makes banding less noticea-
ble. Choose Print Length if you prefer to feed the paper
an exact amount.
Print Quality
Print Length
Adj.
Quality
Auto(GenuinePpr) Specify this mode with paper identified in the Paper Ref-
erence Guide. (See "Displaying the Paper Reference
Guide.") ➔P.313
The printer prints and reads a test pattern for automatic
adjustment of the feed amount. (See "Automatic Banding
Adjustment.") ➔P.488
Auto(OtherPaper) Specify this mode with paper not in the Paper Reference
Guide. (See "Displaying the Paper Reference
Guide.") ➔P.313
The printer prints and reads a test pattern for automatic
adjustment of the feed amount. Note that this function
takes more time and consumes more ink than Auto(Gen-
uinePpr). (See "Automatic Banding Adjustment.") ➔P.488
Manual Use this mode with highly transparent media or other pa-
per for which Auto(GenuinePpr) or Auto(OtherPaper)
cannot be used.
Print a test pattern for adjustment of the feed amount
based on the type of paper. (See "Manual Banding Adjust-
ment.") ➔P.489
iPF770 Menu Settings
User's Guide
Control Panel Printer Menu
419

Canon imagePROGRAF iPF770 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Certification	CE, TUV, Gost-R, WEEE, ErP, EAC, RoHS, WEEE
Product color	Black, Grey
Sound pressure level (printing)	46 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet interface type	Gigabit Ethernet
Media thickness	0.07 - 1.5 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll length	18 m
Media width (sheets)	914.4 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
Borderless printing media sizes	A0, A1, A2, A3, B4
Minimum system requirements	Windows XP, Vista, 7, 8, 8.1, Server 2003/2003R2, Server 2008/2008R2, Server 2012/2012R2 Mac X 10.6.8 - 10.10+
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR
Accuracy	0.2 %
Scan speed (black)	3 ips
Scan speed (color)	1 ips

Weight and Dimensions

Depth	1100 mm
Width	1304 mm
Height	1062 mm
