Canon imagePROGRAF iPF770 User Manual

The roll is empty.
The roll is empty.
Cause Corrective Action
The roll is empty. Follow these steps to replace the used roll with a new roll of the same type and size.
1. Press the Release Lever back and remove the roll.
(See "Removing the Roll from the Printer.") ➔P.327
(See "Removing the Roll Holder from Rolls.") ➔ P.329
2. Load the new roll.
(See "Attaching the Roll Holder to Rolls.") ➔ P.320
(See "Loading Rolls in the Printer.") ➔ P.322
3. If no barcode was printed on the roll, specify the type of paper.
(See "Changing the Type of Paper.") ➔P.325
4. When you have selected ManageRemainRoll > On in the control panel menu and a barcode is not printed
on the roll, also specify the paper length.
(See "Specifying the Paper Length.") ➔ P.326
5. If "Not finished printing. Finish printing remaining jobs?" is shown on the Display Screen, press the
OK button.
Printing will resume, starting from the page on which the error occurred.
If no message appears, printing will continue from the next page.
There is remaining
roll paper, but be-
cause it could not
be advanced, it
could not be detec-
ted.
The unused portion of the roll is heavy, and this is placing a burden on the printer. It may be helpful to change
the printing mode, which will change the paper feed timing.
Choose a higher level of Print Quality in the Advanced Settings of the printer driver.
(See "Giving Priority to Particular Graphic Elements and Colors for Printing.") ➔ P.52
Sheet printing is selected.
Sheet printing is selected.
Cause Corrective Action
You have attempted to print on a sheet, but
no sheet is loaded.
Press ▲ or ▼ to select Load Paper, and then press the OK button. Load a sheet,
and then print.
(See "Loading and Printing on Sheets.") ➔ P.18
Press ▲ or ▼ and select Stop Printing or press the Stop button to stop printing.
Regular printing is selected, but a roll is loaded.
Regular printing is selected, but a roll is loaded.
Cause Corrective Action
A print job for printing on
sheets was sent when a roll is
loaded.
1.
Press ▲ or ▼ to select Remove Roll Paper, and then press the OK button to stop printing.
2. After removing the roll, load and print on a sheet of the type and size of paper you have speci-
fied in the printer driver.
(See "Removing the Roll from the Printer.") ➔P.327
(See "Loading and Printing on Sheets.") ➔ P.18
Press ▲ or ▼ to select Stop Printing, and then press the OK button to stop printing.
The roll is empty. iPF770
User's Guide
Error Message Messages regarding paper
560

Canon imagePROGRAF iPF770 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Certification	CE, TUV, Gost-R, WEEE, ErP, EAC, RoHS, WEEE
Product color	Black, Grey
Sound pressure level (printing)	46 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet interface type	Gigabit Ethernet
Media thickness	0.07 - 1.5 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll length	18 m
Media width (sheets)	914.4 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
Borderless printing media sizes	A0, A1, A2, A3, B4
Minimum system requirements	Windows XP, Vista, 7, 8, 8.1, Server 2003/2003R2, Server 2008/2008R2, Server 2012/2012R2 Mac X 10.6.8 - 10.10+
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR
Accuracy	0.2 %
Scan speed (black)	3 ips
Scan speed (color)	1 ips

Weight and Dimensions

Depth	1100 mm
Width	1304 mm
Height	1062 mm
