Canon imagePROGRAF iPF770 User Manual

Preview
Preview
The Features of Preview ................................................................................................................................. 169
Starting Preview ............................................................................................................................................. 169
Preview Main Window .................................................................................................................................... 170
Dialog Area ..................................................................................................................................................... 172
Enlarge/Reduce the screen display ................................................................................................................. 173
Moving a Page ............................................................................................................................................... 173
Using the ruler ................................................................................................................................................ 173
Priority setting for rotating 90 degrees ............................................................................................................ 174
Printing with Selecting the Layout ................................................................................................................... 175
Print on the Center ......................................................................................................................................... 177
Not Print Spaces at the Top/Bottom ............................................................................................................... 178
The Features of Preview
The Features of Preview
The main features of Preview are as follows.
• While viewing this screen, you can adjust layout settings of a document created with application software.
• You can not only adjust layout settings but also your changes will be instantly applied on the preview screen,
and you can print the preview screen as it is seen.
Note
•
The media type, image size, detailed media settings, and the printer settings can cause the actual print output to
differ from the Preview settings.
Starting Preview
Starting Preview
Follow the procedure below to start the Preview.
1 Start the apllication software which you use.
2 From the application software's File menu, select the printer setup menu to open the Print dialog box.
Note
•
Normally, select Print from the File menu.
3
On the Main sheet, click on the Open Preview When
Print Job Starts check box.
Click the OK button to save the settings.
Note
•
Your printer is depicted in the lower-left area of this screen.
iPF770 The Features of Preview
User's Guide
Windows Software Preview
169

Canon imagePROGRAF iPF770 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Certification	CE, TUV, Gost-R, WEEE, ErP, EAC, RoHS, WEEE
Product color	Black, Grey
Sound pressure level (printing)	46 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet interface type	Gigabit Ethernet
Media thickness	0.07 - 1.5 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll length	18 m
Media width (sheets)	914.4 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
Borderless printing media sizes	A0, A1, A2, A3, B4
Minimum system requirements	Windows XP, Vista, 7, 8, 8.1, Server 2003/2003R2, Server 2008/2008R2, Server 2012/2012R2 Mac X 10.6.8 - 10.10+
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR
Accuracy	0.2 %
Scan speed (black)	3 ips
Scan speed (color)	1 ips

Weight and Dimensions

Depth	1100 mm
Width	1304 mm
Height	1062 mm
