The Features of Free Layout
The Features of Free Layout
The main features of Free Layout are as follows.
• Allows you to lay out at will and print a document created with application software.
• You can not only lay out multiple pages on one page but also lay out and print a multiple-file document on one
page, or lay out and print a document created with multiple application programs on one page.
Note
•
The media type, image size, detailed media settings, and the printer settings can cause the actual print output to
differ from the Free Layout settings.
Starting Free Layout
Starting Free Layout
Follow the procedure below to start the Free Layout.
1 Start the apllication software which you use.
2 From the application software's File menu, select the printer setup menu to open the Print dialog box.
Note
•
Normally, select Print from the File menu.
3 Click on Free Layout in the Page Setup panel to attach a checkmark.
The Features of Free Layout
iPF770
User's Guide
Mac OS Software Free Layout
286
