Advanced Guide
Troubleshooting
Contents
> Routine Maintenance >
When Printing Becomes Faint or Colors Are Incorrect
> Printing the Nozzle Check
Pattern
Printing the Nozzle Check Pattern
Print the nozzle check pattern to determine whether the ink ejects properly from the print head nozzles.
Note
If the remaining ink level is low, the nozzle check pattern will not be printed correctly. Replace the
ink tank whose ink is low.
See
Replacing an Ink Tank
.
You can also print the nozzle check pattern from the printer itself using the
RESUME/CANCEL
button.
1. Make sure that the power is turned on and one or more sheets of A4 or Letter-sized plain paper
are loaded in the Cassette.
2. Open the Paper Output Tray gently, and extend to open the Output Tray Extension.
3. Hold down the
RESUME/CANCEL
button until the
Power
lamp flashes green twice, and then
release it immediately.
The nozzle check pattern will be printed. Do not open the Top Cover while printing is in progress.
Examine the pattern and take an appropriate action.
See
Examining the Nozzle Check Pattern
.
1.
Make sure that the power is turned on and one or more sheets of A4 or Letter-sized
plain paper are loaded in the Cassette.
2.
Open the Paper Output Tray gently, and extend to open the Output Tray Extension.
3.
Open the printer properties dialog box.
See Opening the Printer Properties Dialog Box (Windows)
.
4.
Print the nozzle check pattern.
(1)
Click the Maintenance tab.
(2)
Click Nozzle Check.
(3)
Confirm the displayed message and click Print Check Pattern.
The nozzle check pattern will be printed. Do not open the Top Cover while printing is in progress.
Стр. 49 из 366 стр.Printing the Nozzle Check Pattern
