Cisco ASR 1000 Series Aggregation Services Routers SIP and SPA Software Configuration Guide
OL-14127-08
Configuring the SIP
Configuration Tasks
Note The Cisco ASR1000-SIP40 supports four half-heigh SPAs, two full-height SPAs, and a combination of
two half-height and one full-height SPAs. The Cisco ASR1000-SIP40 does not support double-wide
SPAs and double-high SPAs having two connectors.
The Cisco ASR1000-SIP40 runs on the Cisco ASR1006 and the Cisco ASR 1013 router.
Caution The ASR 1000-SIP40 is not supported on the Cisco ASR 1002, Cisco ASR 1002-F routers, and Cisco
ASR 1004 routers in Cisco IOS XE Software Release 3.1S. Moreover, the ASR1000-SIP40 is supported
only on RP-2 and later route processors (not supported on RP-1). From ESP perspective,
ASR1000-SIP40 is primarily supported on ESP-40. If you are using RP-1 or ESP-10 or ESP-20, you
need to first upgrade the RP-1 to RP-2 followed by upgrading ESP10 or ESP-20 to ESP-40 and then
inserting ESP-40 in the system.
The Cisco ASR1000-SIP40 is also compatible with both Cisco ASR1000-RPs and the Cisco ASR 1000
ESP10, ASR1000-ESP20 and the Cisco ASR1000-ESP40 modules. The LEDs on the modules are the
same for both the Cisco ASR1000-SIP10 and Cisco ASR1000-SIP40.
Hardware Module Scheduling Commands
The following hardware module scheduling commands are supported on the Cisco ASR 1000 Series
Routers.
Ingress Scheduling
Use the following command for ingress scheduling.
Command Purpose
Router(config)# hw-module slot slot-number qos
input [bandwidth value_in_Kbps | strict priority
| weight weight]
This is a global configuration command.
• slot-number—Specifies the number of the SIP
slot.
• bandwidth value_in_Kbps—Sets the
minimum bandwidth in Kbps for QoS
• strict priority—Sets the minimum bandwidth
for a high priority QoS queue
• weight weight—Indicates the excess QoS
scheduling weight
By default, without using this command, each SIP
slot has zero minimum bandwidth and its
scheduled base has an excess sharing weight
proportional to CC’s aggregated bandwidth.
The no form of this command sets scheduling
parameters back to the default.
