For more information, see the OSSI specification document at http://www.cablelabs.com/wp-content/uploads/
specdocs/CM-SP-OSSIv3.0-I02-070223.pdf.
The schemas are supported on Cisco IOS-XE releases.
Table 23: IPDR Schema List for DOCSIS 3.0
Collection MethodSchema DefinitionService DefinitionCategory
time interval, ad-hocDOCSIS-SAMIS-TYPE-1_3.5.1-A.1.xsdSAMIS-TYPE-1SAMIS
time interval, ad-hocDOCSIS-SAMIS-TYPE-2_3.5.1-A.1.xsdSAMIS-TYPE-2
ad-hocDOCSIS-DIAG-LOG-TYPE_3.5.1-A.1.xsdDIAG-LOG-TYPEDiagnostic Log Service
Definition Schemas
eventDOCSIS-DIAG-LOG-EVENT-TYPE_3.5.1-A.1.xsdDIAG-LOG-EVENT-TYPE
time interval, ad-hoc, eventDOCSIS-DIAG-LOG-DETAIL-TYPE_3.5.1-A.1.xsdDIAG-LOG-DETAIL-TYPE
time interval, ad-hocDOCSIS-SPECTRUM-MEASUREMENT-TYPE_3.5.1-A.1.xsdSPECTRUM-MEASUREMENT-TYPESpectrum Management
time interval, ad-hoc, eventDOCSIS-CMTS-CM-REG-STATUS-TYPE_3.5.1-A.1.xsdCMTS-CM-REG-STATUS-TYPECMTS CM Registration Status
Information
time interval, ad-hocDOCSIS-CMTS-CM-US-STATS-TYPE_3.5.1-A.1.xsdCMTS-CM-US-STATS-TYPECMTS CM Upstream Status
Information
ad-hoc, eventDOCSIS-CMTS-TOPOLOGY-TYPE_3.5.1-A.1.xsdCMTS-TOPOLOGY-TYPECMTS Topology
ad-hoc, eventDOCSIS-CPE-TYPE_3.5.1-A.1.xsdCPE-TYPECPE Information
eventDOCSIS-CMTS-US-UTIL-STATS-TYPE_3.5.1-A.1.xsdCMTS-US-UTIL-STATS-TYPECMTS Utilization Statistics
eventDOCSIS-CMTS-DS-UTIL-STATS-TYPE_3.5.1-A.1.xsdCMTS-DS-UTIL-STATS-TYPE
The schemas listed in the table are supported by implementing the respective Collectors, which work as SNMP
agents to generate these IPDR records according to management information of the system.
IPDR CM-STATUS-2008
Cisco IOS-XE Release 16.5.1 supports the IPDR CM-STATUS 2008 version for forward compatibility to
support old IPDR collectors. In the IPDR CM-STATUS 2008 version, the CmtsRcsId and CmtsTcsId objects
are 16 bits in length whereas in the CM-STATUS version both these objects are 32 bits in length.
The CmtsRcsId object in the CM-STATUS-2008 version returns the lower 16 bits of value from the
CM-STATUS version. But, the CmtsTcsId object returns the same value for both the CM-STATUS-2008 and
CM-STATUS version since the value does not exceed 16 bits in both the schemas.
Cisco cBR Series Converged Broadband Routers Troubleshooting and Network Management Configuration
Guide for Cisco IOS XE Fuji 16.8.x
126
Usage-Based Billing (SAMIS)
IPDR Service Definition Schemas
