PurposeCommand or Action
Returns to privileged EXEC mode.end
Example:
Router(cfg-call-home-profile)# end
Step 11
Displays destination profile configuration for the specified profile
or all configured profiles.
show call-home profile {name | all}
Example:
Router# show call-home profile profile1
Step 12
Displays the current Call Home Smart Licensing settings for the
configured destination profiles.
show call-home smart-licensing
Example:
Router# show call-home smart-licensing
Step 13
Displays the Call Home Smart Licensing statistics.show call-home smart-licensing statistics
Example:
Router# show call-home smart-licensing
statistics
Step 14
Copying a Destination Profile
You can create a new destination profile by copying an existing profile.
DETAILED STEPS
PurposeCommand or Action
Enables privileged EXEC mode.enable
Step 1
Example:
Router> enable
•
Enter your password, if prompted.
Enters global configuration mode.configure terminal
Example:
Router# configure terminal
Step 2
Enters Call Home configuration mode.call-home
Example:
Router(config)# call-home
Step 3
Creates a new destination profile with the same configuration
settings as the existing destination profile.
copy profile source-profile target-profile
Example:
Router(cfg-call-home)# copy profile
profile1 profile2
Step 4
• source-profile—Name of the source destination profile.
Cisco cBR Series Converged Broadband Routers Troubleshooting and Network Management Configuration
Guide for Cisco IOS XE Fuji 16.8.x
12
Call Home
Configuring Call Home
