6-6
User Guide for Cisco Digital Media Player Device Manager 5.2.x
OL-15764-03
Chapter 6 Connect to a Presentation System
Procedures
Step 3 Turn On the presentation system.
Step 4 Stop. You have completed this procedure.
Related Topics
• Physical Interfaces (I/O Ports), page 2-4
• Use a Connection that Combines HDMI with DVI, page 6-6
Use a Connection that Combines HDMI with DVI
Timesaver Is your display a touchscreen? If so, this topic is not for you. Instead, see the “Connect to a Touchscreen”
section on page 6-7.
HDMI and DVI differ in their support for audio signals and use connectors that are shaped differently,
but otherwise are identical. Thus, an adapter can help you to connect to your DMP any presentation
system that supports DVI but not HDMI. When you do this, however, you must also use a separate signal
cable to transmit audio signals, or there will not be any audio.
Before You Begin
• Obtain an HDMI-to-DVI adapter.
Procedure
Step 1 Make connections for video.
a. Connect the HDMI cable to the HDMI interface on the back panel of your DMP.
b. Fasten an HDMI-to-DVI adapter to the free end of the cable.
c. Connect the free end of the DVI adapter to the corresponding interface on your presentation system.
Step 2 Make connections for audio.
a. Plug the 3.5mm audio jack into the Audio interface on the back panel of your DMP.
b. Connect the other end of the audio cable to the corresponding interface on your presentation system.
Step 3 If the presentation system is not already turned on, turn it On now.
Step 4 Stop. You have completed this procedure.
Related Topics
• Physical Interfaces (I/O Ports), page 2-4
• Use an HDMI Connection, page 6-5
