Troubleshooting
The following kinds of symptoms sometimes are not malfunctions. First check the following
points before you ask for repair of the unit.
Navigation
Symptom Remedy
GPS reception is not displayed. Connect the antenna cable if it is not
connected.
Reception can be enabled by removing
obstructions, etc.
Positioning is sometimes not possible when
the placement of the satellite is poor.
Display appears by driving the vehicle.
Own vehicle is out of position.
(Other electrical components are attached)
Move attached electrical components
sufficiently away from the unit and the GPS
antenna wire.
Audio
Symptom Remedy
Radio
There is lots of noise. Tune to the correct frequency.

P.11
Stations cannot be tuned to
automatically.
Manually select the station.

P.11
DAB
DAB is not received. Check that “Antenna Power” is set to ON.

P.42
Or move to a place with good reception.
The selected service is not played
while DAB is being received.
The selected service might not be
broadcasting. Select a service currently
broadcasting.
Setting screens
1
MENU
2
Set image quality using
respective keys.
Day/Night Mode:
Switch to the day screen or night
screen.
The screen can be made easier to
view by manually switching to the
day screen, for example, when the
headlights are lit during the day
and the screen is difficult to view.
When Auto is selected, the screen
automatically switches to the night
screen when the parking light is lit.
MEMO:
•Whentheenginekeyisturnedto
the“OFF”positionthenbacktothe
“ON”position, Auto isset.
Brightness:
Adjust the image quality
by
or .
Image quality adjustments can
be set for both the day and night
screens.
During Smartphone linking, the
image quality of the smartphone
application screen can be adjusted.
Other settings
1
MENU
2
Set the functions using
respective keys.
DivX
®
VOD:
Displays the code required for
setting DivX VOD content to a
playable state (Register state) or
unplayable state (Deregister state).
This also changes the state
(Register state/Deregister state) of
the device being played.
Linked Device:
Sets the smartphone to be
connected when Smartphone
linking is performed. (Default:
iPhone)
Browser Cache:
Deletes the Browser cache.
Use this function when errors occur
on Intelligent VOICE or Intelligent
VOICE does not work correctly
even though the smartphone is
connected to the unit correctly.
Antenna Power:
Switches power ON/OFF of the
DAB antenna. (Default: ON)

Clarion NX505E Specifications

General

Widescreen	-
Display diagonal	6.2 \
Display resolution	800 x 480 pixels
AM band range	531 - 1602 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, DAB, FM
Built-in camera	No
Lifetime map updates	Roads change, but with Lifetime Map Updates your map will always be up to date. Start fresh every few months by downloading a new edition of the industry's most accurate map. New editions are issued four times per year.
Storage media type	Memory card
Compatible memory cards	MicroSD (TransFlash)
Product color	Black

Weight and Dimensions

Depth	157 mm
Width	178 mm
Height	100 mm
Weight	- g
