5 Surveillance Mode Configuration D-Link Smart Managed Switch User Manual
126
PoE Information
This page displays the Power-over-Ethernet(PoE) usage information of each port on the Switch. The port
number, PoE status, health status, PoE budget and power consumption is listed for each port. It is possible
to click on the health status to be re-directed to the Health Diagnostic page. Hover-over each field to get
more information about each value.
Figure 5.10 – Surveillance Mode > PoE Information
PoE Scheduling
This PoE Scheduling page allows user to specify the amount of time that power is delivered to a PoE port.
This can be used to save power when devices are not in use, or as a security feature to prevent wireless
access from being available outside of business hours, for example. It is possible to set a schedule name, a
start time, and end time and which ports the PoE schedule applies to.
Figure 5.11 – Surveillance Mode > PoE Scheduling
The fields that can be configured in the Time Profile section are described below:
Parameter Description
Profile Name
Specifies the name of the time range schedule.
Time(HH MM)
Select the start time end time with hour and minutes.
Weekdays
Specifies the work day for the scheduling.
