D-Link DGS-1210-10 User Manual

5 Surveillance Mode Configuration D-Link Smart Managed Switch User Manual
128
SNTP State
Specifies to enable or disable the SNTP state.
SNTP Poll Interval (30-99999)
Specifies the poll interval. The range is between 30 and 99999. By
default, the value is 30 seconds.
Click the Apply button to implement changes made.
The fields that can be configured for SNTP Server Settings are described below:
Parameter Description
SNTP First Server
Select to enter the IPv4 or IPv6 address for SNTP first server.
SNTP Second Server
Select to enter the IPv4 or IPv6 address for SNTP second server.
Click the Apply button to add the SNTP server to the configuration.
Surveillance Settings
The Surveillance Settings page allows user to configure the settings for the Surveillance VLAN. This is a
VLAN dedicated for IP-Camera (IPC) and Network Video Recorders (NVR), and also can be used to manage
surveillance devices on the network.
Figure 5.14 – Surveillance Mode > Surveillance Settings
The fields that can be configured for the Surveillance Settings are described below:
Parameter Description
VLAN ID (2-4094)
Specifies a VLAN ID for the surveillance VLAN in the range between 2
and 4094.
Click the Apply button to implement changes made.
The fields that can be configured for the IP Settings are described below:

D-Link DGS-1210-10 Specifications

General

Switching Capacity	20 Gbps
Forwarding Rate	14.88 Mpps
MAC Address Table Size	8K
VLANs	256
Jumbo Frame	9, 216 bytes
Fanless Design	Yes
Humidity	5% to 95% non-condensing
Ports	8 x 10/100/1000Base-T, 2 x SFP
Dimensions	280 x 180 x 44 mm
Operating Temperature	0 to 40 °C
Storage Temperature	-40 to 70 °C
