4 Web-based Switch Configuration D-Link Smart Managed Switch User Manual
2
2
9
9
Figure 4.12 – Tool Menu > Reset System
Reboot Device
Provide a safe way to reboot the system. Select YES or NO to save the current settings before action. And
click Reboot to restart the switch.
Figure 4.13 – Tool Menu > Reboot Device
Configuration Backup and Restore
Allow the current configuration settings to be saved to a file (not including the password), and if necessary,
you can restore configuration settings from this file. Two methods can be selected: HTTP or TFTP.
Figure 4.14 – Tool Menu > Configure Backup and Restore
HTTP: Backup or restore the configuration file to or from your local drive.
Backup/Restore Config ID Number: Select config_id 1 or config_id 2.
Click Backup to save the current settings to your disk.
Click Choose File to browse your inventories for a saved backup settings file.
Click Restore after selecting the backup settings file you want to restore.
TFTP: TFTP (Trivial File Transfer Protocol) is a file transfer protocol that allows you to transfer files to a
remote TFTP server. Specifies the configuration 1 or 2 to be specified, TFTP Server IP Address with IPv4
or IPv6 address and TFTP File Name for the configuration file you want to save to / restore from.
Click Backup to save the current settings to the TFTP server.
Click Restore after selecting the backup settings file you want to restore.
Note: Switch will reboot after restore, and
all current configurations will be lost.
