8 About the System
Embosser Component (Top, Front, and Right Side)
Cable Guide The cable guide keeps the interconnect data cable between
the printer and embosser hidden.
Printer Mounting Pins The mounting pins align the printer with the embosser.
Card Transfer Area The card transfer area receives the card from the printer
component and places it in position for embossing and
indenting.
Printer Mounting Lock The mounting lock secures the printer to the embosser.
Embosser Supplies
Access Door
The embosser supplies access door provides access to the
indent ribbon and topping foil cartridges.
Embosser Access Door
Lock
The embosser access door lock provides secure access to the
embosser supplies.
Card Output Hopper The card output hopper holds up to ten completed cards.
Cable Guide
Printer
Mounting Pins
Card Output
Hopper
Printer Mounting Pin
Card Transfer Area
Printer Mounting Lock
Embosser Supplies
Access Door
Embosser Access
Door Lock
