Dell XC Core XC760 User Manual

Table 5. Rear view of the system with 2 x 2.5-inch rear drive module(continued)
Item Ports, panels, or slots Icon Description
by turning on the system ID button. You can also use the system ID
button to reset iDRAC and to access BIOS using the step through
mode. When pressed, the system ID LED in the back panel blinks until
either the front or rear button is pressed again. Press the button to
toggle between on or off mode.
NOTE: If the server stops responding during POST, press and
hold the System ID button for more than five seconds to enter
the BIOS progress mode
NOTE: To reset the iDRAC (if not disabled on the iDRAC setup
page by pressing F2 during system boot), press and hold the
System ID button for more than 15 seconds.
12 OCP NIC card (optional) N/A The OCP NIC card supports OCP 3.0. The NIC ports are integrated
on the OCP card which is connected to the system board.
13 NIC ports (optional) The NIC ports that are integrated on the LOM card provide network
connectivity which is connected to the system board.
14 Power supply unit (PSU1) PSU1 is the primary PSU of the system.
Inside the system
This section provides an overview of the internal components of the system, both with and without the expansion risers.
Dell XC Core XC760 overview
13

Dell XC Core XC760 Specifications

General

Brand	Dell
Model	XC Core XC760
Category	Server
Language	English
