5.1.2.3. EtherCAT® specifications 
Interface 
Data interface 
EtherCAT® 
Data Rate 
100 Mbps Full Duplex bus speed 
Max. Sample Rate 
DualCore: 20 kS/sec, HD 10 kS/sec, HS 40 kS/sec 
Max. Throughput per Chain 
From 6 MB/s to 10 MB/s 
Sync Accuracy 
Below 1 sample to Sirius® 
EtherCAT® 
Max. Cable Length 100m 
Max. Number of Units 
64 or more (power injectors may be required) 
Data Interface Connection 
LEMO 1T EtherCAT® hybrid cable 
Single cable for data, power and sync, daisy chainable 
5.1.3. Data transfer combinations 
DEWESoft® can only acquire data from Dewesoft Hardware which uses the DS-EtherCAT+ protocol. 
The SIRIUS EtherCAT® slices have 2 modes of operation: 
● Buffered mode: for DEWESoft® software 
● Standard EtherCAT® mode: for standard EtherCAT® masters 


 
