DEWESOFT SIRIUS Series User Manual

/
SIRIUS
® 
TECHNICAL REFERENCE MANUAL 


4.11.2. SIRIUS-R8: Specifications 

R8 
R8B 
R8D 
R8DB 
Computer 
Processor 
Intel® Core™ i7; 4x 2.0 GHz base, 2.8 GHz max; 8 threads 
Memory 
8 GB (optional up to 32 GB) 
Storage 
500 GB removable SATA SSD 
Option: 1 TB removable SATA SSD 
Option: 250 GB mSATA internal SSD 
Interfaces and options 
USB 
Front: 4x USB 3.0 
Front: 4x USB 3.0 
Front: 3x USB 3.0, 1x USB 
2.0 
Rear: 4x USB 3.0 
Front: 3x USB 3.0, 1x USB 
2.0 
Rear: 4x USB 3.0 
Ethernet 
Standard: 2x GLAN (RJ45) 
Optional: 1x GLAN (RJ45), 1x WLAN (RP-SMA Female Jack) 
EtherCAT® 
1x EtherCAT® 100 Mbps Full Duplex, 8-pin LEMO female, 8 A (shared with power out connector) 
Power out 
Switched input supply on 2-pin LEMO female, 8 A (shared with EtherCAT® connector) 
Synchronization 
2x SIRIUS® SYNC 
Video 
1x DVI-I (VGA and HDMI compatible) 
GPS (option) 
10 Hz or 100 Hz or 100 Hz + RTK 
GPS display (option) 
External on DSUB-9 female connector + remote power on 
Analog out option 
up to 64 channels 
- 
- 
- 
Display 
Type 
- 
- 
17'', Full-HD, Multi-touch 
display 
17'', Full-HD, Multi-touch 
display 
Resolution 
- 
- 
1920 x 1080 
1920 x 1080 
Brightness 
- 
- 
400 cd/m² 
400 cd/m² 
Batteries 
Battery type 
- 
NL2024HD 
- 
NL2024HD 
Number of batteries 
- 
4, hot swappable 
- 
4, hot swappable 
Voltage 
- 
14.4 V 
(at fully charged state 
16.8 V) 
- 
14.4 V 
(at fully charged state 
16.8 V) 
Total capacity of single 
battery 
- 
6.25 Ah 
- 
6.25 Ah 
Discharge current of 
single battery 
- 
8 A 
- 
8 A 
Wrong polarity 
protection 
- 
YES 
- 
YES 
Battery weight 
- 
0.65 kg 
- 
0.65 kg 
Power 
Power supply 
12 - 36 V DC 
18 - 24 V DC 
12 - 36 V DC 
18 - 24 V DC 
Power consumption 
Typ. 28 W (Max. 56 W) 
(excl. SIRIUS® slices) 
Typ. 28 W (Max. 56 W) 
(excl. SIRIUS® slices) 
Typ. 45 W (Max. 73 W) 
(excl. SIRIUS® slices) 
Typ. 45 W (Max. 73 W) 
(excl. SIRIUS® slices) 
Charging power 
- 
60 W 
- 
60 W 
Environmental 
SIRIUS
®
V20-1 88 / 336  
