SIRIUS
®
TECHNICAL REFERENCE MANUAL
5.23.2. Standalone digital signal conditioner
In this mode, you use DEWESoft® to do the configuration once and then you can use the SIRIUS® slice
a pure, standalone signal conditioner. Just connect the power-supply and the signal amplifier will be
operational: No PC, DEWESoft® software, USB connection required. Since the signal processing is done
in the SIRIUS PLC there is only a minimal delay of some 10 samples between the input and output.
Any physical input signal is converted to an output voltage of max. ±10 V.
Note: The SIRIUS-HD slices do not support signal conditioning.
Features:
● Input: any analog channel
● Signal conditioning
● Scaling
● Offset
● Gain
● Redundant DAQ system
● Simple math functions
● Standalone operation possible
Principle of Signal conditioning
SIRIUS
®
V20-1 256 / 336
