SIRIUS
®
TECHNICAL REFERENCE MANUAL
4.10.6. SIRIUS-R2/R4: Rear side
SIRIUS-R4 Rear side
On the back side of the SIRIUS-R4 you can find these connectors:
Name
Description
AO 1 to 8
Analog out BNC connectors (optional)
EtherCAT IN
EtherCAT® slave port (optional)
8-pin LEMO male connector
EtherCAT OUT
EtherCAT® slave port (optional)
8-pin LEMO female connector
Important
See chapter “EtherCAT® slave port” for details.
SIRIUS
®
V20-1 82 / 336
