SIRIUS

® 

TECHNICAL REFERENCE MANUAL 



Hint 

You can use the analog input, analog output and counters at the same time. 

5.12.2.1. MULTI: Voltage 



Voltage - Single ended 



Voltage – Differential 

Use only when sensor Output (+) and Output (-) 

are referenced to Gnd. Gnd must be connected.



5.12.2.2. MULTI: Current 

External direct shunt 



External loop powered shunt 



SIRIUS

V20-1 168 / 336  
