SIRIUS
®
TECHNICAL REFERENCE MANUAL
Continuous short to ground
Bridge Connection Types
Full / Half / Quarter bridge (3-wire)
2 mV/V…1000 mV/V free programmable with Dual Core
Internal Bridge
Completion
½ bridge 1 kΩ and ¼ bridge 120 Ω and 350 Ω
Typ. Bridge Completion
Accuracy
0.05 %; TCR: 5 ppm/K (others on request)
Internal Shunt Resistor
100 kΩ, software selectable (others on request)
Typ. Shunt Resistor
Accuracy
0.05 %; TCR: 10 ppm/K (others on request)
Input Short, Sensor
Offset Adjust
Counters (only on STGM+ type)
1 digital counter input
3 digital inputs
Fully synchronised with analog data
Alarm output
counting, waveform timing, encoder, tacho, gear-tooth sensor
General Counter
Specifications
counting, waveform timing, encoder, tacho, gear-tooth sensor
Additional Specifications
DSUB-9, 8-pin LEMO-2B, 16-pin LEMO-2B (others on request)
Standard + DSI® adapters
SIRIUS
®
V20-1 176 / 336
