OPERATION
L025317 Issue 1 March 2011 3-23
SWITCHING ON AND OFF
WARNINGS: (1) The laser marking system must only be used
for its intended purpose.
(2) The laser marking system may only be
operated by trained personel.
(3) Operation is only allowed with all required
cables connected and all parts mounted.
Do not disconnect any cables during operation.
(4) Refer also to PART 1 : “HEALTH & SAFETY” .
CAUTION: The lens cap, used to prevent damage or external soiling that
will cause a reduction in laser performance, must be removed
before operation.
Switching On the Control Unit
At the control panel, release the On/Off button by turning it clockwise. Wait
until the SERVER RUNNING indicator has illuminated.
Switching On the Laser Head
Turn the key switch from position "0" to position "1". To start the laser turn
the key clockwise to the laser symbol and hold it for at least 1 second. The
key automatically turns back to position "1".
(a) For 30 Watt systems, the laser needs a warm-up phase.
(b) For 55 Watt systems, the laser needs a warm-up phase and tests
whether the laser is ready by printing a test print; so there is a very
fast test print before a print signal.
Please follow laser safety precautions before and after switching on
the laser.
The PRINTER BUSY indicator will illuminate when the laser
hardware is switched on.
The PRINTER READY indicator illuminates. After initialising the
Dynamark 3 software and starting the lasers, the marking system is ready.
Laser emission is also displayed by a red LED on the rear of the laser unit.
Switching Off the Laser Head
(1) Turn the key switch from position "1" to position "0". The laser
hardware is switched off.
Switching Off the Control Unit
(1) Press the On/Off button. The computer will switch off automatically. at
once
