11Installation and Service Guide: Color Controller E-46A
Introduction
• Server software: The E-46A software. Runs on Windows operating system.
Document conventions
Note: The NOTE format highlights important messages and additional information.
How the E-46A operates
When a customer prints, the motherboard and printer interface board process image data. The printer interface board
is a custom board and allows the E-46A to communicate with the printer. The CPU controls the transfer of image data
to and from the motherboard and runs the PostScript interpreter. DIMM holds image data during printing.
The interpreter rasterizes the page description file and compresses the image pattern into memory using compression
technology. The interpreter outputs the compressed raster data through the image frame buffer memory to the printer
interface board. The raster data is sent to the printer, which then renders the image on paper at maximum speed.
Before you service the E-46A
Before you service the E-46A, it is strongly recommended that you make sure that you have the required tools (see
“Tools you will need” on page 11) and carefully review all precautions (see “Precautions” on page 12).
Also, keep in mind that the most common cause of a hardware problem is a faulty or loose connection. Before you
replace an expensive component, check internal and external connections (see page 50).
Tools you will need
To install or service the E-46A, you will need the following tools and parts:
• ESD wrist grounding strap and antistatic mat
• Flathead screwdriver
• #0, #1, and #2 Phillips head screwdrivers
When servicing the Fiery QuickTouch, use a screwdriver with a magnetic tip.
• Needlenose pliers
DANGER
The DANGER icon indicates a warning concerning operations which, if not performed correctly,
may lead to death or injury. To use the E-46A safely, always pay attention to WARNING icons and
messages.
The WARNING icon indicates a caution concerning operations which, if not performed correctly,
may lead to injury. To use the E-46A safely, always pay attention to CAUTION icons and messages.
The CAUTION icon indicates operational requirements and restrictions. To operate the E-46A
correctly and avoid damage to the E-46A or other property, always pay attention to IMPORTANT
icons and messages.
