42Installation and Service Guide: Color Controller E-46A
Using the E-46A
Network status LEDs
Two LEDs next to the network connector indicate the network link status and speed. For additional information about
network setup, see Configuration and Setup, which is part of the user documentation set.
Figure 20: Ethernet network port
Table 1: Network link indicators
Table 2: Network speed indicators
Starting, shutting down, restarting, and rebooting
You can leave the E-46A running all the time. Restarting the E-46A resets the E-46A system software, but does not
reboot the entire system. Network access to the E-46A is temporarily interrupted and all the jobs processing currently
are terminated.
To start or shut down the E-46A when power synchronization is ON
1 Make sure that the power synchronization in enabled (see page 23).
1 Link/Activity LED
2 Speed LED
Link/Activity LED Network link status
Off No link to network
Solid green Valid link to network
Flashing green Data transfer is in progress
Speed LED Network speed
Off 10 Megabits/second
Green 100 Megabits/second
Amber 1000 Megabits/second
Remember that when the E-46A is powered off, network access to the printer is interrupted.
Always obtain permission from the network administrator before you take the E-46A off the
network.
Unless instructed otherwise by a troubleshooting procedure, always use the procedures in this
section to shut down the E-46A. Do not use the power button on the side of the Fiery QuickTouch
to shut down the E-46A.
