84Installation and Service Guide Color Controller E-46A
Replacing parts
2 Position the hard disk drive inside the hard disk drive bracket and align the front-most mounting holes on the hard
disk drive with the four holes in the bracket.
When correctly installed, the hard disk drive extends about an inch past the rear of the bracket.
3 Replace the four screws that you removed earlier to attach the hard disk drive to the bracket.
4 Slide the bracket all the way onto the shelf and lock it by moving the latch toward the front panel.
Note: You will encounter slight resistance as you slide the bracket onto the shelf. The resistance is caused by two
tension points on the bottom of the bracket. The resistance helps control the bracket’s movement during removal
and installation.
5 Secure the hard disk drive bracket to the hard disk drive shelf using the screws that you removed earlier.
6 Connect one end of the hard disk drive data cable to the hard disk drive and the other end to SATA1 (J41) on the
motherboard (see Figure 33 on page 61).
7 Connect the power cable to the hard disk drive.
8 Reassemble the E-46A (see page 86).
9 If you replaced the hard disk drive with a new hard disk drive, install system software (see page 101).
If a startup error displays on the Fiery QuickTouch when you power on the E-46A, check the connections.
10 Verify functionality (see page 86).
DVD drive
The DVD drive is installed in the front of the chassis. The drive is used to install system software and archive data on
writable media.
To remove the DVD drive
1 Shut down the E-46A, remove all cables from the back, and then open the system (see page 51).
To access the DVD drive, you must remove the left, right, and front panels from the chassis.
2 Remove the data/power cables from the dual connector on the back of the DVD drive.
If you are removing the cable assembly to replace it with a new cable assembly, detach the other ends of the cables
from the motherboard and the power supply.
Avoid striking the DIMMs as you replace the hard disk drive bracket.
