Configuring Multiple Authentication Methods
SecureStack C2 Configuration Guide 23-33
Configuring Multiple Authentication Methods
About Multiple Authentication Types
Whenenabled,multipleauthenticationtypesallowuserstoauthenticateusingmorethanone
methodonthesameport.Inorderformultipleauthenticationtofunctiononthedevice,each
possiblemethodofauthentication(MACauthentication, 802.1X,PWA)mustbeenabledglobally
andconfiguredappropriatelyonthedesiredportswithitscorresponding
commandsetdescribed
inthischapter.
Multipleauthenti cationmodemustbegloballyenabledonthedeviceusingthesetmultiauth
modecommand.
Configuring Multi-User Authentication (User + IP phone)
TheUser+IPphonemulti‐userauthenticationfeatureallowsauserandtheirIP phonetobothuse
asingleportontheC2buttohaveseparatepolicyroles.
ʺUser+IPPhoneʺAuthenticationontheSecureStackC2isimplementedbyassigninganingressed
packetreceivedonaport
toapolicyrolebasedontheVLANthepacketwasassignedto,andnot
thepacketʹssourceMACaddress.Therefore,onaportconfiguredforUser+IPPhone
Authentication,thereexiststwodifferentVLAN‐to‐policyrolemappings.
ThepolicyrolefortheIP phoneisstatically
mappedusingtheVLAN‐to‐policymappingfea ture
whichassignsanypacketsreceivedwithaVLANtagsettoaspecificVID(forexample,Voice
VLAN)toanindicatedpolicyrole(forexample,IPPhonepolicyrole).Therefore,itisrequiredthat
IPphoneisconfiguredtosendVLANtaggedpackets
tothe“Voice”VLAN.RefertotheUsage
sectionforthecommand“setpolicyrule”onpage 11‐10foradditionalinformation.
Thesecondpolicyrole,fortheuser,caneitherbestaticallyconfiguredwiththedefaultpolicyrole
ontheportordynamicallyassignedthroughauthenticationtothenetwork.When
thedefault
policyroleisassignedonaport,theVLANsetastheportʹsPVIDismappedtothedefaultpolicy
role.Whenapolicyroleisdynamicallyappliedtoaportastheresultofasuccessfully
authenticatedsession,the“authenticatedVLAN”ismappedtothepolicy
rolesetintheFilter‐ID
returnedfromtheRADIUSserver.The“authenticatedVLAN”mayeitherbethePVIDoftheport,
ifthePVIDOverrideforthepolicyprofileisdisabled,ortheVLANspecifiedinthePVIDOverride
ifthePVIDOverrideisenabled.
Commands
Note: C2 devices support up to six authenticated users per port.
Note: The only Multi-User Authentication supported on the C2 is User + IP phone. The IP phone
has to authenticate using 802.1x or MAC authentication, but the User may authenticate using
802.1x, PWA, or MAC authentication.
For information about... Refer to page...
show multiauth 23-34
set multiauth mode 23-35
clear multiauth mode 23-35
