Epygi QX series Administrator's Guide

QX5
QXFXO4/QXISDN4/QXE1T1/QXFXS24; (SW Version 6.0.x) 108
QXFXO4/QXISDN4/QXE1T1/QXFXS24 Manual II: Administrator’s Guide
mail service activation, etc. Clicking on the details information will open the RTP Statistics page where all RTP parameters of established call are
provided.
• Authenticated By information details the callers that passed an authentication on the QX gateway as configured in the Local AAA Table.
• Information about FAX statistics for the calls that have a FAX transmission handled. It only appears when there was a FAX transmission during
the call. Clicking on the FAX details link in the Details column will move to the
FAX Statistics page.
The Call Detail column is present only in the Unsuccessful Calls table and indicates the reason why the call was unsuccessful.
The Filter performs a search procedure by the selected criteria. The search may be done with several criteria at the same time.
The Records per page are used to select the number of displayed statistic records per page. The Previous and Next can be utilized to switch between
these pages.
The Download Call Detail Records links are available below for all Call History tables (for administrator's access only) and allows you to download the
displayed Call History in a text file.
CDR Settings
The CDR Settings page offers the following input options:
The Enable Call Reporting checkbox enables Call History reporting. The selected number of statistics entries will be displayed in the Call History tables.
The
Maximal Number of Displayed Call Records
drop down lists
are used to select the number of Successful, Missed and
Unsuccessful Outgoing statistics entries to be displayed in the
corresponding Call History tables. If the record numbers exceed
the numbers specified in these drop down lists, the oldest record
will be removed.
The Download All Call Detail Records link is used to download
the entire displayed statistics in a file that can be viewed with a
simple text editor. This type of Call History file is easy-to-read and
can be displayed in a spreadsheet.
The Download All Call Detail Records (CSV format) link is used
to download the entire displayed statistics in CSV (Comma-
Separated Values) formatted file.
The
Clear all Records
button is used to clear all statistics records.
Fig.II- 167: Call History – CDR Settings page
When the number of Call History entries exceeds the numbers specified in the CDR Settings page, the oldest entries are being automatically deleted. In
order to keep the Call History entries safe, QX IP PBX allows you to configure the
Automatic Backup service of the Call History.
Automatic Backup
The Automatic Backup page is used to configure the automatic downloading of the call statistics. Two options of downloading the call statistics are
available: uploading the call statistics file to the server or sending it to the mailing address. This page consists of the following components:
