Fujitsu PRIMERGY TX1310 M5 User Manual

9.3.2 Removing slot brackets
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools:
– Phillips PH2 / (+) No. 2 screw driver
–
Hexagon screw driver (for hexagon bolt)
Removing a slot bracket
▶
Remove the two screws.
▶
Remove the controller from the mounting tabs on the slot bracket.
9.4
Installing an expansion card
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Software: 5 minutes
Tools: Only for installing slot brackets:
–
Phillips PH2 / (+) No. 2 screw driver
–
Hexagon screw driver (for hexagon bolt)
Preliminary steps
▶
"Suspending BitLocker functionality" on page 61
.
▶
"Unlocking the server" on page 39.
▶
"Removing the bay cover" on page 40.
▶
"Shutting down the server" on page 41.
▶
"Disconnecting the power cord" on page 42.
▶
"Getting access to the component" on page 43.
Expansion cards
116 Upgrade and Maintenance Manual TX1310 M5
