Replacing the M.2 SSD
▶
Remove the defective M.2 SSD, see "Removing the M.2 SSD" on page 202.
▶
Install the new M.2 SSD, see
"Installing the M.2 SSD" on page 198.
Concluding steps
▶
If applicable, install an expansion card, see "Installing an expansion card"
on page 118.
▶
Install the front fan, see "Installing the new front fan" on page 108.
▶
"Reassembling" on page 50.
▶
"Connecting the power cord" on page 56.
▶
"Switching on the server" on page 57.
▶
"Installing the bay cover" on page 58.
▶
"Locking the server" on page 59.
Software configuration
To install the ESXi to the M.2 SSD, see "Software configuration" on
page 200.
15.6 System board
15.6.1 Replacing the system board
Field Replaceable Unit
(FRU)
Hardware: 50 minutes
Software: 10 minutes
System board and components
TX1310 M5 Upgrade and Maintenance Manual 205
