Status Description
green on The server is switched on.
HDD/SSD activity indicator (2)
Status Description
green flashing Data access in progress.
17.2.2.3 Indicators on the drives
Figure 158: Indicators on the drives
1 ODD activity indicator 2 RDX drive Power-on indicator
ODD activity indicator (1)
ODDs may have an indicator or not.
Appendix A
TX1310 M5 Upgrade and Maintenance Manual 231
