The second hole is for M.2 SSDs with 110 mm length (see orange
circles). If necessary, move the M.2 lock to the second hole, see
"Moving the M.2 lock to the second hole" on page 196.
15.5.2 Installing an M.2 SSD
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Software: 15 minutes
Tools: tool-less
Preliminary steps
▶
"Unlocking the server" on page 39
.
▶
"Removing the bay cover" on page 40.
▶
"Shutting down the server" on page 41.
▶
"Disconnecting the power cord" on page 42.
▶
"Getting access to the component" on page 43.
▶
Remove the front fan, see "Removing the defective front fan" on page 106.
▶
If applicable, remove an expansion card, see "Removing an expansion
card" on page 119.
Moving the M.2 lock to the second hole
This step is only necessary when installing M.2 SSDs with 110 mm
length.
System board and components
196 Upgrade and Maintenance Manual TX1310 M5
