17.2.3 Server rear
17.2.3.1 Connectors on the I/O panel
Figure 159: Connectors on the I/O panel
1 LAN connectors (2x)
2
USB 3.2 connectors (2x)
3
USB 2.0 connectors (4x)
4 Video connector (Display Port)
5 Serial interface (optional)
Some of the devices that can be connected may require special drivers
(see the documentation for the connected device).
Appendix A
TX1310 M5 Upgrade and Maintenance Manual 233
