17.4 Minimum startup configuration
Field Replaceable Units
(FRU)
If the server does not start up or other problems occur, it may be necessary to
take the system down to its most basic configuration in order to isolate the
defective component.
The minimum startup configuration consists of the following components and
cables:
Component Notes
System board no TPM or expansion cards installed
1 CPU with heat sink installed in slot CPU 1
1 memory module installed in slot DIMM-1A
1 PSU installed on chassis
Table 5: Minimum startup configuration - components
Cable Notes
Power cable
Table 6: Minimum startup configuration - cables
▶
"Unlocking the server" on page 39
▶
"Removing the bay cover" on page
40
▶
"Shutting down the server" on page 41
▶
"Disconnecting the power cord" on page 42.
▶
Take the system down to its minimum startup configuration.
▶
"Connecting the power cord" on page 56.
▶
Connect a display to the server.
▶
"Switching on the server" on page 57
▶
"Installing the bay cover" on page 58
▶
"Locking the server" on page 59
Appendix A
236 Upgrade and Maintenance Manual TX1310 M5
