Figure 52: Positions of the system fans
1 Rear fan (Fan2 SYS)
2
CPU fan (implemented in the heat
sink)
3
Front fan (Fan1 SYS)
The CPU fan is implemented in the heat sink. When the CPU fan is
defective, the heat sink must be replaced, see "Replacing the heat sink"
on page 148
.
8.3 Replacing the rear fan
Upgrade and Repair Unit
(URU)
Hardware: 15 minutes
Tools: diagonal pliers
Fans
98 Upgrade and Maintenance Manual TX1310 M5
