CHAPTER 3: INTERFACES SOFTWARE INTERFACE
850 FEEDER PROTECTION SYSTEM – INSTRUCTION MANUAL 3–61
5. To select the SR settings file used for initialization, click the Initialize Settings from SR
Settings File button.
6. To locate and select the file to convert, click the button beside the Initialize Settings
from SR Settings File box.
CAUTION:
EnerVista 8 Series Setup version 1.2x and above supports conversion of all 750/760
files as long as they are from a 32-bit PC. If the file is 16-bit, it must be converted to 32-
bit using the latest 350 EnerVista Setup before doing the 850 conversion.
7. Click OK to begin the conversion and complete the process. Once this step is
completed, the new file, with a complete path, is added to the EnerVista 8 Series
Setup software environment.
Conversion Summary
Report
At the end of the conversion process, the results are summarized in a conversion report.
The report is found under Device Definition in the offline file window.
Figure 3-29: Conversion Report in Offline Window
CAUTION:
For future reference, make a printout of the conversion report immediately after the
conversion in case conversion reports are removed or settings modified from the 8
Series Setup Software.
