CHAPTER 10: STATUS VIRTUAL INPUTS
850 FEEDER PROTECTION SYSTEM – INSTRUCTION MANUAL 10–9
Virtual Inputs
Path: Status > Virtual Inputs 1(X)
The state of all virtual inputs is shown here, see next figure. The value for each Virtual Input
is shown on the control panel graphically as a toggle switch in either the On (|) state or the
Off (O) state.
Figure 10-6: Status of Virtual Inputs, HMI
Figure 10-7: Status of Virtual Inputs, Enervista 8 Series Setup software
Virtual Outputs
Path: Status > Virtual Outputs
The state of all virtual outputs is shown here, see next figure. The value for each Virtual
Output is shown on the control panel graphically as a toggle switch in either the On (|) state
or the Off (O) state.
Figure 10-8: Status of Virtual Outputs, HMI
