[8] Analog input X30/12
[9] Analog Input X42/1
[10] Analog Input X42/3
[11] Analog Input X42/5
[100] Bus feedback 1
[101] Bus feedback 2
[102] Bus feedback 3
CL-04 Feedback 2 Conversion
Option: Function:
See par. CL-01 Feedback 1 Conversion for details.
[0] * Linear
[1] Square root
[2] Pressure to temperature
CL-06 Feedback 3 Source
Option: Function:
See par. CL-00 Feedback 1 Source for details.
[0] * No function
[1] Analog input 53
[2] Analog input 54
[3] Pulse input 29
[4] Pulse input 33
[7] Analog input X30/11 (OPCGPIO)
[8] Analog input X30/12 (OPCGPIO)
[9] Analog Input X42/1 (OPCAIO)
[10] Analog Input X42/3 (OPCAIO)
[11] Analog Input X42/5 (OPCAIO)
[100] Bus feedback 1
[101] Bus feedback 2
[102] Bus feedback 3
CL-07 Feedback 3 Conversion
Option: Function:
See par. CL-01 Feedback 1 Conversion for details.
[0] * Linear
[1] Square root
[2] Pressure to temperature
CL-20 Feedback Function
Option: Function:
This parameter determines how the three possible feedbacks will be used to control the output frequency
of the frequency converter.
[0] Sum Sum [0] sets up the PID Controller to use the sum of Feedback 1, Feedback 2 and Feedback 3 as the
feedback.
AF-600 FP High Power Operating Instructions
100
7
