Par. No. # Parameter description Default value 4-set-up Change during opera-
tion
Conver-
sion index
Type
SP-1# SP-10 Line failure [0] No function All set-ups FALSE - Uint8 SP-11 Line Voltage at Input Fault ExpressionLimit All set-ups TRUE 0 Uint16
SP-12 Function at Line Imbalance [0] Trip All set-ups TRUE - Uint8
SP-2# SP-23 Typecode Setting null 2 set-ups FALSE - Uint8 SP-25 Trip Delay at Torque Limit 60 s All set-ups TRUE 0 Uint8
SP-26 Trip Delay at Drive Fault ExpressionLimit All set-ups TRUE 0 Uint8
SP-28 Production Settings [0] No action All set-ups TRUE - Uint8
SP-29 Service Code 0 N/A All set-ups TRUE 0 Int32
SP-3# SP-30 Current Lim Ctrl, Proportional Gain 100 % All set-ups FALSE 0 Uint16 SP-31 Current Lim Ctrl, Integration Time 0.020 s All set-ups FALSE -3 Uint16
SP-32 Current Lim Ctrl, Filter Time 26.0 ms All set-ups TRUE -4 Uint16
SP-4# SP-40 VT Level 66 % All set-ups FALSE 0 Uint8 SP-41 Energy Savings Min. Magnetization ExpressionLimit All set-ups TRUE 0 Uint8
SP-42 Energy Savings Min. Frequency 10 Hz All set-ups TRUE 0 Uint8
SP-43 Motor Cosphi ExpressionLimit All set-ups TRUE -2 Uint16
SP-5#
SP-50 RFI Filter [1] On 1 set-up FALSE - Uint8 SP-53 Fan Monitor [1] Warning All set-ups TRUE - Uint8 SP-6# SP-60 Function at Over Temperature [0] Trip All set-ups TRUE - Uint8 SP-61 Function at Drive Overload [0] Trip All set-ups TRUE - Uint8
SP-62 Drive Overload Derate Current 95 % All set-ups TRUE 0 Uint16
SP-7# SP-8# SP-9#
7.2.8 SP-## Special Functions
AF-600 FP High Power Operating Instructions
130
7
