GE af-600 fp User Manual

Par. No. # Parameter description Default value 4-set-up Change during opera-
tion
Conver-
sion index
Type
AP-0# AP-00 External Interlock Delay 0 s All set-ups TRUE 0 Uint16 AP-2# AP-20 Low Power Auto Set-up [0] Off All set-ups FALSE - Uint8 AP-21 Low Power Detection [0] Disabled All set-ups TRUE - Uint8
AP-22 Low Speed Detection [0] Disabled All set-ups TRUE - Uint8
AP-23 No-Flow Function [0] Off All set-ups TRUE - Uint8
AP-24 No-Flow Delay 10 s All set-ups TRUE 0 Uint16
AP-26 Dry Pump Function [0] Off All set-ups TRUE - Uint8
AP-27 Dry Pump Delay 10 s All set-ups TRUE 0 Uint16
AP-3# AP-30 No-Flow Power 0.00 kW All set-ups TRUE 1 Uint32 AP-31 Power Correction Factor 100 % All set-ups TRUE 0 Uint16
AP-32 Low Speed [RPM] ExpressionLimit All set-ups TRUE 67 Uint16
AP-33 Low Speed [Hz] ExpressionLimit All set-ups TRUE -1 Uint16
AP-34 Low Speed Power [kW] ExpressionLimit All set-ups TRUE 1 Uint32
AP-35 Low Speed Power [HP] ExpressionLimit All set-ups TRUE -2 Uint32
AP-36 High Speed [RPM] ExpressionLimit All set-ups TRUE 67 Uint16
AP-37 High Speed [Hz] ExpressionLimit All set-ups TRUE -1 Uint16
AP-38 High Speed Power [kW] ExpressionLimit All set-ups TRUE 1 Uint32
AP-39 High Speed Power [HP] ExpressionLimit All set-ups TRUE -2 Uint32
AP-4#
AP-40 Minimum Run Time 10 s All set-ups TRUE 0 Uint16 AP-41 Minimum Sleep Time 10 s All set-ups TRUE 0 Uint16 AP-42 Wake-up Speed [RPM] ExpressionLimit All set-ups TRUE 67 Uint16
AP-43 Wake-up Speed [Hz] ExpressionLimit All set-ups TRUE -1 Uint16
AP-44 Wake-up Ref./FB Difference 10 % All set-ups TRUE 0 Int8
AP-45 Setpoint Boost 0 % All set-ups TRUE 0 Int8
AP-46 Maximum Boost Time 60 s All set-ups TRUE 0 Uint16
AP-5#
AP-50 End of Curve Function [0] Off All set-ups TRUE - Uint8 AP-51 End of Curve Delay 10 s All set-ups TRUE 0 Uint16 AP-6# AP-60 Broken Belt Function [0] Off All set-ups TRUE - Uint8 AP-61 Broken Belt Torque 10 % All set-ups TRUE 0 Uint8
AP-62 Broken Belt Delay 10 s All set-ups TRUE 0 Uint16
AP-7# AP-75 Short Cycle Protection [0] Disabled All set-ups TRUE - Uint8 AP-76 Interval between Starts start_to_start_min_on_time (P2277) All set-ups TRUE 0 Uint16
AP-77 Minimum Run Time 0 s All set-ups TRUE 0 Uint16
AP-8# AP-80 Flow Compensation [0] Disabled All set-ups TRUE - Uint8 AP-81 Square-linear Curve Approximation 100 % All set-ups TRUE 0 Uint8
AP-82 Work Point Calculation [0] Disabled All set-ups TRUE - Uint8
AP-83 Speed at No-Flow [RPM] ExpressionLimit All set-ups TRUE 67 Uint16
AP-84 Speed at No-Flow [Hz] ExpressionLimit All set-ups TRUE -1 Uint16
AP-85 Speed at Design Point [RPM] ExpressionLimit All set-ups TRUE 67 Uint16
AP-86 Speed at Design Point [Hz] ExpressionLimit All set-ups TRUE -1 Uint16
AP-87 Pressure at No-Flow Speed 0.000 N/A All set-ups TRUE -3 Int32
AP-88 Pressure at Rated Speed 999999.999 N/A All set-ups TRUE -3 Int32
AP-89 Flow at Design Point 0.000 N/A All set-ups TRUE -3 Int32
AP-9#
AP-90 Flow at Rated Speed 0.000 N/A All set-ups TRUE -3 Int32
7.2.17 AP-## HVAC Appl. Param.
