525-600 V, unit sizes 4X, 5X and 6X
AF-600 FP
Bussmann
E125085
JFHR2
Amps
SIBA
E180276
JFHR2
Ferraz-Shawmut
E76491
JFHR2
Internal
Option
Bussmann
150 HP 170M3017 315 2061032.315 6.6URD30D08A0315 170M3018
200 HP 170M3018 350 2061032.35 6.6URD30D08A0350 170M3018
250 HP 170M4011 350 2061032.35 6.6URD30D08A0350 170M5011
300 HP 170M4012 400 2061032.4 6.6URD30D08A0400 170M5011
350 HP 170M4014 500 2061032.5 6.6URD30D08A0500 170M5011
400 HP 170M5011 550 2062032.55 6.6URD32D08A550 170M5011
Table 3.7: Unit Size 41, 42, 43, and 44, 525-600 V
AF-600 FP
Bussmann PN* Rating Ferraz Siba
450 HP 170M4017 700 A, 700 V 6.9URD31D08A0700 20 610 32.700
500 HP 170M4017 700 A, 700 V 6.9URD31D08A0700 20 610 32.700
600 HP 170M6013 900 A, 700 V 6.9URD33D08A0900 20 630 32.900
650 HP 170M6013 900 A, 700 V 6.9URD33D08A0900 20 630 32.900
Table 3.8: Unit Sizes 51 and 52, 525-600 V
AF-600 FP
Bussmann PN* Rating Siba Internal Bussmann Option
750 HP 170M7081 1600 A, 700 V 20 695 32.1600 170M7082
950 HP 170M7081 1600 A, 700 V 20 695 32.1600 170M7082
1050 HP 170M7081 1600 A, 700 V 20 695 32.1600 170M7082
1150 HP 170M7081 1600 A, 700 V 20 695 32.1600 170M7082
1350 HP 170M7082 2000 A, 700 V 20 695 32.2000 170M7082
Table 3.9: Unit Sizes 61, 62, 63, and 64, 525-600 V
AF-600 FP
Bussmann PN* Rating Siba
750 HP 170M8611 1100 A, 1000 V 20 781 32. 1000
950 HP 170M8611 1100 A, 1000 V 20 781 32. 1000
1050 HP 170M8611 1100 A, 1000 V 20 781 32. 1000
1150 HP 170M8611 1100 A, 1000 V 20 781 32. 1000
1350 HP 170M8611 1100 A, 1000 V 20 781 32. 1000
Table 3.10: Unit Sizes 61, 62, 63, and 64, 525-600 V
*170M fuses from Bussmann shown use the -/80 visual indicator, -TN/80 Type T, -/110 or TN/110 Type T indicator fuses of the same size and amperage may be
substituted for external use.
3.1.14 Motor Insulation
For motor cable lengths ≤ the maximum cable length listed in the General Specifications tables the following motor insulation ratings are recommended because
the peak voltage can be up to twice the DC link voltage, 2.8 times the mains voltage, due to transmission line effects in the motor cable. If a motor has lower
insulation rating it recommended to use a du/dt or sine wave filter.
Nominal Mains Voltage Motor Insulation
U
N
≤ 420 V
Standard U
LL
= 1300 V
420 V < U
N
≤ 500 V
Reinforced U
LL
= 1600 V
500 V < U
N
≤ 600 V
Reinforced U
LL
= 1800 V
AF-600 FP High Power Operating Instructions
25
