Par. No. # Parameter description Default value 4-set-up Change during opera-
tion
Conver-
sion index
Type
ID-0# ID-00 Operating Hours 0 h All set-ups FALSE 74 Uint32 ID-01 Running Hours 0 h All set-ups FALSE 74 Uint32
ID-02 kWh Counter 0 kWh All set-ups FALSE 75 Uint32
ID-03 Power Up's 0 N/A All set-ups FALSE 0 Uint32
ID-04 Over Temp's 0 N/A All set-ups FALSE 0 Uint16
ID-05 Over Volt's 0 N/A All set-ups FALSE 0 Uint16
ID-06 Reset kWh Counter [0] Do not reset All set-ups TRUE - Uint8
ID-07 Reset Running Hours Counter [0] Do not reset All set-ups TRUE - Uint8
ID-08 Number of Starts 0 N/A All set-ups FALSE 0 Uint32
ID-1# ID-10 Trending Source 0 2 set-ups TRUE - Uint16 ID-11 Trending Interval ExpressionLimit 2 set-ups TRUE -3 TimD
ID-12 Trigger Event [0] False 1 set-up TRUE - Uint8
ID-13 Trending Mode [0] Trend always 2 set-ups TRUE - Uint8
ID-14 Samples Before Trigger 50 N/A 2 set-ups TRUE 0 Uint8
ID-2# ID-20 Historic Log: Event 0 N/A All set-ups FALSE 0 Uint8 ID-21 Historic Log: Value 0 N/A All set-ups FALSE 0 Uint32
ID-22 Historic Log: Time 0 ms All set-ups FALSE -3 Uint32
ID-23 Historic Log: Date and Time ExpressionLimit All set-ups FALSE 0 TimeOfDay
ID-3#
ID-30 Alarm Log: Error Code 0 N/A All set-ups FALSE 0 Uint8 ID-31 Alarm Log: Value 0 N/A All set-ups FALSE 0 Int16 ID-32 Alarm Log: Time 0 s All set-ups FALSE 0 Uint32
ID-33 Alarm Log: Date and Time ExpressionLimit All set-ups FALSE 0 TimeOfDay
ID-4# ID-40 Drive Type 0 N/A All set-ups FALSE 0 VisStr[6] ID-41 Power Section 0 N/A All set-ups FALSE 0 VisStr[20]
ID-42 Voltage 0 N/A All set-ups FALSE 0 VisStr[20]
ID-43 Software Version 0 N/A All set-ups FALSE 0 VisStr[5]
ID-44 GE Model Number 0 N/A All set-ups FALSE 0 VisStr[40]
ID-45 Actual Typecode String 0 N/A All set-ups FALSE 0 VisStr[40]
ID-46 GE Product No. 0 N/A All set-ups FALSE 0 VisStr[8]
ID-47 GE Power Card Model No 0 N/A All set-ups FALSE 0 VisStr[8]
ID-48 Keypad ID Number 0 N/A All set-ups FALSE 0 VisStr[20]
ID-49 SW ID Control Card 0 N/A All set-ups FALSE 0 VisStr[20]
ID-5#
ID-50 SW ID Power Card 0 N/A All set-ups FALSE 0 VisStr[20] ID-51 Drive Serial Number 0 N/A All set-ups FALSE 0 VisStr[10] ID-53 Power Card Serial Number 0 N/A All set-ups FALSE 0 VisStr[19]
ID-6#
ID-60 Option Mounted 0 N/A All set-ups FALSE 0 VisStr[30] ID-61 Option SW Version 0 N/A All set-ups FALSE 0 VisStr[20] ID-62 Option Ordering No 0 N/A All set-ups FALSE 0 VisStr[8]
ID-63 Option Serial No 0 N/A All set-ups FALSE 0 VisStr[18]
7.2.14 ID-## Drive Information
AF-600 FP High Power Operating Instructions
136
7
